750W 220V 3.5N*M 2000RPM synchronous motor for packaging equipment

Name: 750W 220V 35NM 2000RPM synchronous motor for packaging equipment
Brand: SZGH
Price: 1 USD

China 750W 220V 3.5N*M 2000RPM synchronous motor for packaging equipment wholesale

Brand Name : SZGH

Model Number : SZGH-09075BC

Certification : CE

Place of Origin : Shenzhen, China

MOQ : 1 set

Price : negotiation

Payment Terms : TT in advance / Western Union / Paypal /LC/Alipay/Creditcard

Supply Ability : 300 sets per month

Delivery Time : within 3-5 days upon receipt of full payment

Packaging Details : Packaged with International Standard

Frame Size : 86mm

Rated Power : 750W

Continuous Torque : 3.5NM

Peak Torque : 10.5NM

Rated Speed : 2000RPM

Rated Current : 3A

Rated Voltage : 220V

Rotor Inrtia : 3.4kg.m^2*10e-4

Encoder Resolution : 2500PPR

Diameter of Axle : 16mm

Weight : 3.9

Matched Driver : SZGH-201/301/020M

Contact Now

750W 220V 3.5N*M 2000RPM CNC servo motor for Manufacture

SZGH-09075BC is 750W servo motor and middle inertia with high performance and , compare with 09075DC model, it is more bigger torque with 3.5NM, very popular model.

There are two kinds type servo driver, SZGH-020M,SZGH-201 & SZGH-301 that matching for 750W servo motor.

There is also one dual servo driver,SZGH-302,that can control two pcs of 750W servo motors synchronously.

Application

CNC Machinery,printing equipment, packaging equipment, textile equipment, laser processing equipment,

robotics, automated production lines, such as processing precision, processing efficiency and reliability, and other

requirements of the relatively high equipment.

750W 220V 3.5N*M 2000RPM synchronous motor for packaging equipment

Specifications

750W 220V 3.5N*M 2000RPM synchronous motor for packaging equipment

Dimension
